Magnet Size: 1.811″x1.622″x.5″
(46mmx41.2mmx12.7mm)
Colors: White
Installation Instructions
- The TANE SQZMAG-1840 magnet is designed to be installed in the recessed channel, located at the top of a metal entry/exit door.
- The magnet can be squeezed to fit into the channel.
- We recommend cleaning the channel before installing the magnet.
- Install the magnet in a position opposite the switch.
- Applying a silicone adhesive to the magnet will protect the magnet from moisture, dirt and dislocation.
Outline Dimensions Unit: inch(mm)
