The TWC PIR345 utilizes a dual element pyroelectric infrared sensor. It’s able to accurately detect the human infrared spectrum, and features a high-sensitivity setting with low false alarm rates.
This product is widely used for Banks, Post Offices, Malls, Private Homes, Jewelry Stores, Hotels and similar places where a high level of security is required.
Product Features
- Instant 5 Minute Walk-Test, Accepts all Signals, No More Boxing During Installations
- Ball-Joint Mount, for Easy Position Adjustments
- Triple-Tested before Shipping to Ensure Reliability
- Wall mount installation.
- Outstanding detection range and reliability.
- Compatible with most 2GIG and Honeywell systems
- Multi-Zone False Alarm Protection
- Low battery warn by LED flashing
- Temperature compensition
- PIR sensitivity adjustment
- 12m detection Range with Wider Angle Lens
Specifications
Scroll or swipe left to right on the table below for more information.
| Sensing angle | 120° |
| Sensor range | 30 ftx40 ft |
| Suggested Installation Height | 7.2 ft. above floor level |
| Sensor type | Dual element pyroelectric infrared sesnor |
| Transmitter Frequency | 345Mhz |
| Wireless Signal range | >300 ft (open air, line of sight) |
| Battery type | One (1) CR2/CR15270 3V Lithium Battery or equivalent |
| Battery life | 3-5 years |
| Operating temperature | 14~122°F |
| Relative Humidity | 5~90% no condensation |
| Dimensions | 3.51 inx2.06 inx1.32 in |
 |  |
 | |
